Description
| Features |
| • 2.0 million pixels，1/3″HD color CMOS |
| • 1080P/60fps, 720@30fps |
| • 4 Digital Microphones Array and 10 meters voice pickup |
| • Wired connection with speakerphone / external microphone |
| • Adopt AEC & ANS & AGC technology |
| • 20X optical zoo |
| • Camera automatically rotates and tracks the voice |
| • USB3.0 / HDMI / 3.5mm line in micro / line out speaker interface |
| • With IR remote control |
PRODUCT SPECIFICATION
| Category |
Specification |
| CAMERA, LENS PARAMETERS |
|
| Image Sensor |
1/3inch HDCMOS |
| Min Lux |
0.1Lux(F1.2) |
| Effective Piexl |
2.4 MP |
| Zoom |
20X Optical & 12X Digital |
| Shutter Speed |
1 to 1/10000s |
| Horizontal Field of View |
61° (W) 3.64°(T) |
| Frame Rate |
1920×1080,1280×720, 640×480 |
| Focus Mode |
Auto |
| Aperture Mode |
Auto |
| Backlight Compensation |
Support |
| Wide Dynamic |
Support |
| Picture Adjustment |
Brightness, Chroma, Saturation, Contrast Acutance |
| MICROPHONE PARAMETERS |
|
| MIC Array Quantity |
4 |
| MIC Array Form |
Linear |
| Microphone Spacing |
45.8mm |
| MIC Array Quantity |
4 |
| MIC Array Form |
Linear |
| Microphone Spacing |
45.8mm |
| Sampling Rate |
16KHz/48KHz |
| Sensitivity |
-26dBFs |
| Far-field Pick up Voice Distance |
0-10meters |
| Horizontal Voice Pick up Angle |
Horizontal 180° |
| SNR |
65.5dB |
| Communication Mode |
full duplexuplex |
| INTERFACE PARAMETERS |
|
| Video Interface |
USB3.0 HDMI |
| Video Compressed Format |
MJPG/H.264 |
| Control Interface |
RS-232, USB2.0, UVC |
| Control Agreement |
VISCA/PELCO-D/PELCO-P |
| Communicate Baud Rate |
2400/4800/9600/11520/19200/38400 |
| Power Interface |
DC-038 power socket（DC12V） |
| PTZ PARAMETERS |
|
| Pan Rotation |
-170°~ +173° |
| Tilt Rotation |
-30°~ +90° |
| Horizontal Rotate Speed |
0.1~100°/second |
| Vertical Rotate Speed |
0.1~80°/ second |
| OTHER PARAMETERS |
|
| Power Adapter |
Input AC100V~AC240V Output DC12V/2A |
| Decoder |
Built in |
| Input voltage |
DC12V |
| Power Consumption |
12W(MAX ） |
| Storage Temperature and Humidity |
0°C ~ +60°C / 20% ~ 95% |
| Working temperature and Humidity |
-10°C ~ +50°C / 20% ~ 80% |
| Operating Environment |
Indoor |
| Size |
180180172mm |
| Weight |
1.360g |
High-Definition Imaging: 2.0 MP 1/3″ HD Color CMOS Sensor for superior image clarity.
Crystal-Clear Video: Supports 1080P at 60fps and 720P at 30fps for smooth, high-quality video.
Advanced Audio Capture: Equipped with a 4-microphone array and 10-meter voice pickup range.
Versatile Connectivity: Includes USB3.0, HDMI, and 3.5mm line in/out for flexible audio and video integration.
Innovative Technologies: Features AEC (Acoustic Echo Cancellation), ANS (Automatic Noise Suppression), and AGC (Automatic Gain Control) for optimal sound quality.
Powerful Zoom Capabilities: 20X optical zoom and 12X digital zoom for detailed, close-up views.
Intelligent Tracking: Automatic rotation and voice tracking for dynamic video recording.
Convenient Remote Control: Includes an IR remote control for easy operation.
Flexible PTZ Control: Pan rotation of -170° to +173°, tilt rotation of -30° to +90°, with adjustable rotation speeds.
