Description
4K Resolution @ 60fps: Enjoy ultra-clear video due to 4K resolution and 60fps professional conferencing and streaming
Advanced PTZ Camera: Easily operate pan, tilt, and zoom with 12x optical zoom for capturing every minute detail.
Automatic Subject Tracking: Features auto-framing and voice-tracking for focused, dynamic video conferencing.
Digital Noise Reduction: Equipped with 2D and 3D noise reduction for superior image clarity in various lighting conditions.
Flexible White Balance Options: Includes automatic, manual, and custom settings to adapt to different environments.
Versatile Connectivity: Includes HDMI, Type-C, and RJ45 interfaces, along with multiple video compression standards for broad compatibility.
| TECHNICAL SPECIFICATIONS |
|
|
| CAMERA |
Video Resolution |
HDMI(Optional):4K60fps, 4KP29.97fps, 4KP25, 1080P30, 1080P29.29, 1080P25 |
|
|
| Sensor |
1/2.5″, CMOS, Effective Pixel: 8.5M |
|
| Scanning Mode |
Progressive Scan |
|
| Lens |
12x, f4.4mm ~ 52.8mm, F1.8 ~ F2.6 |
|
| Minimal Illumination |
0.5 Lux @ ( F1.8, AGC ON) |
|
| Shutter |
1/30s ~ 1/10000s |
|
| White Balance |
Automatic, indoor, outdoor, one-button, manual, specified color temperature |
|
| Backlight Compensation |
Support |
|
| Digital Noise Reduction |
2D & 3D Digital Noise Reduction |
|
| Signal-to-noise ratio |
55dB |
|
| Vertical Angle of View |
71˚ ~ 8.2˚ |
|
| Horizontal Rotation Range |
42.7˚ ~ 4.5˚ |
|
| Vertical Rotation Range |
±170° |
|
| Pan Speed Range |
-30˚ ~ +90˚ |
|
| Tilt Speed Range |
1.7˚ ~ 100˚/s |
|
| H & V Flip |
1.7˚ ~ 69.9˚/s |
|
| Image Freeze |
Support |
|
| PoE power Supply |
Support |
|
| Humanoid Tracking |
Support (optional) |
|
| Number of Preset |
255 |
|
| Preset Accuracy |
0.1˚ |
|
| USB FEATURES |
Support Operating System |
Window 7, Window 8, Window 10, Mac OS X, Linux, Android |
|
| Color space/compression |
YUY2/MJPEG/H.264/H.265 |
|
| Video Format |
YUY2:up to 1080p/30; H.264 AVC: up to 2160p/60; H.264 SVC: up to 2160p/60;
MJPEG: up to 2160p/30; H.265: up to 2160/60; |
|
| USB Audio |
Support |
|
| USB Video Communication Protocol |
UVC 1.1 ~ 1.5 |
|
| UVC PTZ Control |
Support |
|
NETWORK
CHARACTERISTICS |
Video Coding Standard |
H.264/H.265/MJPEG |
|
| Video Stream |
The first stream, the second stream |
|
| Resolution of the second stream |
3840×2160, 1920×1080, 720×576, 720×480, 320×240 |
|
Video bitrate
Rate Control |
32 kbps ~ 102400 kbps
Variable bit rate, fixed bit rate |
|
| Frequency |
50 Hz: 1fps ~ 50fps,60 Hz: 1 fps ~ 60fps |
|
| Audio compression Standard |
AAC, G711A |
|
| Audio Bit Rate |
96Kbps, 128Kbps, 256Kbps |
|
| Supporting Agreement |
TCP/IP, HTTP, RTSP, RTMP/RTMPS, Onvif, DHCP, SRT, GB/T28181, multicast etc |
|
| INPUT/OUTPUT INTERFACE |
HD Output |
1 channel, HDMI: version 2.0; |
|
| Network interface |
1 Channel, RJ45:10M/100M/1000M, adaptive Ethernet: support PoE power supply: |
|
| Audio Port |
1 channel, 3.5mm, Audio In; 1 way, Line Out; |
|
USB Interface
Power connector |
1way, Type-C socket, can output up to 4k@60fps compressed video and 1080p
orignal video;
JEITA type (DC IN 12V) |
|
| Communication Interface |
1 channel, RS232 In: 8-pin small DIN, maximum distance 30 meters, VISCA/Pelco-D/Pelco-P protocol;
1 channel, RS232 Out:8-pin small DIN, maximum distance 30 meters, VISCA protocol networking:
1 channel, RS485: 2-pin Phoenix port, maximum distance: 1200 meters, VISCA/
Pelco-D/Pelco-P protocol; |
|
| Power Connector |
JEITA type (DC IN 12V) |
|
GENERIC
SPECIFICATION |
Input voltage |
DC 12V/PoE (802.3af) |
|
| Input current |
1.0A (max) |
|
| Operating temperature |
-10 ˜ 40˚ C |
|
| Stored temperature |
-40 ˜ 60˚ C |
|
| Power consumption |
12W (max) |
|
| Size |
169mm x 142mm x 164mm |
|
| Weight |
1.35Kg |
|
